Synonym : Through Coat Ultrasonic Thickness Gauge, Thru Coat Ultrasonic Thickness Gauge
Caltech India offers Through Coating Ultrasonic Thickness Gauge. Multi-mode Ultrasonic Thickness Gauge MT-600 with through coating Pulse-Echo mode (P-E mode) and Echo-Echo mode (E-E mode) two modes width measuring instrument.
The model MT- 600 is a multi-mode ultrasonic thickness gauge. Based on the same operating principles as SONAR, the instrument is capable of measuring the thickness of various materials with accuracy as high as 0.1/0.01 millimeters. The Multi-mode feature of the gauge allows the user to toggle between pulse-echo mode (flow and pit detection), and echo-echo mode (eliminate paint or coating thickness)
Model MT-600 Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials. Transducer models are available for special application, including for coarse grain material and high temperature applications.
Multi-mode: Pulse-Echo mode (P-E mode) and Echo-Echo mode (E-E mode). In Echo-Echo mode, it can test the wall thickness eliminating paint or coating thickness. Wide measuring range: Pulse-Echo mode: (0.65～600)mm (in Steel). Echo-Echo mode: (2.5～100)mm V-Path correction to compensate the nonlinearity of the probe. It has function for online transfer of the measured data to PC via USB.
Multi-mode Ultrasonic thickness gauge adopts the theory of sound wave to measure a wide range of material, such as metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials. Main functions are given below:
Main Technical Parameters:
|Display||320×240 TFT color LCD screen, adjustable backlight brightness|
|Measuring Range||Two Working Modes: Pulse-Echo mode: (0.65～600)mm (in Steel). Echo-Echo mode: (2.5～100)mm|
|Sound Velocity Range||1000~9999 m/s|
|Accuracy||±(0.04mm (≤10mm): ±0.4%H(>10mm)|
|Units||Metric / English unit selectable|
|Communication||Support Bluetooth and USB2.0 communication, the host program can be uploaded online|
|Memory||Memory upto 100 files (upto 100 values for each file) of stored value|
|Power Supply||Two “AA” size, 1.5 volt alkaline batteries. 100 hours typical operating time (EL backlight off)|
|Dimension||150 x 76 x 38 mm|
|Net Weight||295 g|
|MT-600||Through Coating Ultrasonic Thickness Gauge|
